Application and description
This cable is suitable for residential buildings, kitchens, lighting service rooms or portable lighting instruments.
Due to its special insulation and sheath compound, these cables are adapted to kitchens and heating, and are
used in areas with higher temperatures (such as lighting systems) without contact with heated parts and radiation.
It is not suitable for outdoor use, cannot be used in industrial and agricultural buildings or non-domestic portable
tools, the maximum conductor temperature in normal use: 90 ° C. When used at high temperatures, skin contact
must be avoided.
Standards and certifications
CEI 20-20/12, CEI 20-35 (EN60332-1) / CEI 20-37 (EN50267), CENELEC HD 21.12 S1 /EN50265-2-1
Cable construction
- Flexible bare copper conductor
- Complies with DIN VDE 0295 cl. 5, IEC 60228 cl. 5 and HD 383
- PVC insulation T13 complies with VDE-0281 Part 1
- Yellow-green ground wire (three cores and above)
- Color coding complies with VDE-0293-308
- PVC outer sheath TM3
Technical characteristics
- Working voltage: 300/500 V
- Test voltage: 2000 V
- Dynamic bending radius: 15 x Ø
- Static bending radius: 4 x Ø
- Operating temperature in application: +5º C to +90º C
- Flame retardant: IEC 60332.1
- Insulation resistance: 20 MΩ x km
Cable parameters：
|
Number of cores x conductor cross-sectional area
# x mm²
|
Nominal insulation thickness mm
|
Nominal outer diameter mm
|
Nominal copper weight kg/km
|
Nominal cable weight kg/km
|
Number of cores x conductor cross-sectional area
# x mm²
|
|
H05V2V2-F
|
|
2 x 0.75
|
0.6
|
0.8
|
6.2
|
14.4
|
54.2
|
|
3 x 0.75
|
0.6
|
0.8
|
6.6
|
21.6
|
65
|
|
4 x 0.75
|
0.6
|
0.8
|
7.1
|
29
|
77.7
|
|
5 x 0.75
|
0.6
|
0.9
|
8
|
36
|
97.3
|
|
2 x 1.00
|
0.6
|
0.8
|
6.4
|
19
|
60.5
|
|
3 x 1.00
|
0.6
|
0.8
|
6.8
|
29
|
73.1
|
|
4 x 1.00
|
0.6
|
0.9
|
7.6
|
38
|
93
|
|
5 x 1.00
|
0.6
|
0.9
|
8.3
|
48
|
111.7
|
|
2 x 1.50
|
0.7
|
0.8
|
7.4
|
29
|
82.3
|
|
3 x 1.50
|
0.7
|
0.9
|
8.1
|
43
|
104.4
|
|
4 x 1.50
|
0.7
|
1.0
|
9
|
58
|
131.7
|
|
5 x 1.50
|
0.7
|
1.1
|
10
|
72
|
163.1
|
|
2 x 2.50
|
0.8
|
1.0
|
9.2
|
48
|
129.1
|
|
3 x 2.50
|
0.8
|
1.1
|
10
|
72
|
163
|
|
4 x 2.50
|
0.8
|
1.1
|
10.9
|
96
|
199.6
|
|
5 x 2.50
|
0.8
|
1.2
|
12.4
|
120
|
245.4
|
|
3 x 4.00
|
0.8
|
1.2
|
11.3
|
115
|
224
|
|
4 x 4.00
|
0.8
|
1.2
|
12.5
|
154
|
295
|
|
5 x 4.00
|
0.8
|
1.4
|
13.7
|
192
|
361
|
|
3 x 6.00
|
0.8
|
1.1
|
13.1
|
181
|
328
|
|
4 x 6.00
|
0.8
|
1.3
|
13.9
|
230
|
490
|
|
H05V2V2H2-F
|
|
2 x 0.75
|
0.6
|
0.8
|
4.2 x 6.8
|
14.1
|
48
|
|
2 x 1.00
|
0.6
|
0.8
|
4.4 x 7.2
|
19
|
57
|
Product AdvantagesHeat-Resilient PVC Construction Ensuring SafetyThe unique insulation and sheath compounds of H05V2V2 series resist higher operating temperatures without degradation. Flame-retardant and mechanically enduring, they offer reliable performance in environments like kitchens or light fixtures—enhancing safety standards within cable manufacturing protocols that demand risk-aware design.Flexible Stranding for Smooth, Adaptable InstallationClass 5 stranded copper cores grant exceptional bendability, enabling neat routing through cabinetry, lighting conduits, or movable setups. The cables are especially appreciated by installers in tight or frequently reconfigured indoor spaces, improving installation quality and longevity—a significant benefit for wire manufacturers and installers.Harmonized Standards Support Seamless ComplianceThe cables comply with harmonized European standards including EN 50525‑2‑11 and related certification marks (CEI/EN 60332‑1, EN 50267, EN 50265‑2‑1). This ensures compatibility and streamlined specification management for industrial cable suppliers looking to integrate safe, approved components into their offerings. Use ScenariosAppliance Technicians Wiring in Warm Domestic ZonesProfessionals installing or repairing kitchen or laundry area appliances benefit from H05V2V2 cables’ heat resistance and flexibility. The cable supports safe connections amid ambient heat and limited space—aligning with cable manufacturing expectations for appliance-grade reliability.Office Fit-Out Crews Handling Portable EquipmentDuring office setup or renovation, wiring often traverses modular furniture or workstation layouts. These cables’ flexibility and thermal robustness offer practical solutions for routing power cords to devices and task lighting efficiently, satisfying the adaptability needs of wire and cable integrators.Building Maintainers Upgrading Interior Circuits SafelyMaintenance teams in residential or commercial buildings require cables that perform under heat-limited zones without compromising safety. H05V2V2 series cables’ design suits upgrades in lighting circuits, heating-adjacent pathways, or appliance retrofits—making them a preferred choice among industrial cable suppliers supporting safe infrastructure upgrades.
About UsJINDA CABLE is a trusted partner in wire and cable manufacturing, committed to delivering technically advanced, safety-first solutions. From flexible heat-resistant lines like the H05V2V2 family to power, control, and photovoltaic cabling, the company supports domestic, commercial, and light industrial sectors. Engineers, integrators, and cable manufacturing professionals rely on JINDA for certified quality, design integrity, and global compliance.Request A Quote For H05V2V2‑F Flat And Round Power Cable Solutions Today! FAQWhat temperature conditions can these cables handle?They operate up to +90 °C in mobile use and +90 °C when fixed, with short-circuit tolerance to +150 °C.Are they safe near hot surfaces?They resist elevated ambient heat but must not be in direct contact with hot surfaces or radiation to avoid skin contact risk.What standards do they comply with?They meet EN 50525‑2‑11 along with flame and insulation safety standards like IEC 60332‑1.How flexible are these cables?They support dynamic bending at 15× diameter and static bending at 4×, designed for installation ease.Can they be used outdoors?No. They are strictly intended for indoor use in residential or office settings only.
