This cable is suitable for use in medium-sized mechanical equipment in humid environments, such as refrigerators,
washing machines, dehydrators and other household appliances. As long as it meets the appropriate equipment specifications, these cables are also suitable for use in cooking and heating equipment, ensuring that there is no
direct contact with hot parts of the equipment or any other heat source. Some other applications of this cable include:
fixed installation in furniture, partition walls, decoration, and reserved building facilities. They are not suitable for
outdoor use, industrial (except clothing manufacturing) or agricultural applications. The maximum operating voltage
for single-phase or three-phase systems is Uo/U
318/550 V. In direct systems, the maximum operating voltage is Uo/U 413/825 V.
Application and Description
This cable is suitable for use in medium-sized mechanical equipment in humid environments, such as
refrigerators,washing machines, dehydrators and other household appliances. As long as it meets the
appropriateequipment specifications, these cables are also suitable for use in cooking and heating
equipment,ensuring that there is nodirect contact with hot parts of the equipment or any other heat
source. Someother applications of this cable include:fixed installation in furniture, partition walls,
decoration, andreserved building facilities. They are not suitable foroutdoor use, industrial (except
clothing manufacturing)or agricultural applications. The maximum operating voltagefor single-phase
or three-phase systems is Uo/U318/550 V. In direct systems, the maximum operating voltage is Uo/U
413/825 V.
Standards and certifications
CEI 20-20/5 / 20-35 (EN60332-1) /20-52, 0.5 - 2.5mm² in accordance with BS6500, 4.0mm² in accordance with
BS7919, 6.0mm² in accordance with BS7919, VDE0281, CENELEC HD21.5, CE low voltage 73/23/EEC & 93/68/
EEC directives., ROHS certification
Cable construction
- Flexible bare copper conductor
- In accordance with DIN VDE 0295 cl. 5, BS 6360 cl. 5, IEC 60228 cl. 5 and HD 383 standards
- PVC insulation T12 type, in accordance with VDE-0281 part 1
- Color coding in accordance with VDE-0293-308
- Yellow-green ground wire (three cores and above)
- PVC outer sheath TM2
Technical characteristics
- Working voltage: 300/500 V
- Test voltage: 2000 V
- Dynamic bending radius: 7.5 x Ø
- Static bending radius: 4 x Ø
- Operating temperature during application: -5º C to +70º C
- Flame retardant: IEC 60332.1
- Insulation resistance: 20 MΩ x km
Cable parameters：
|
Number of cores x conductor cross-sectional area # x mm² |
Nominal insulation thickness mm |
Nominal outer diameter mm |
Nominal copper weight kg/km |
Nominal cable weight kg/km |
Number of cores x conductor cross-sectional area # x mm² |
|
|
H05VV-F |
||||||
|
2 x 0.75 |
0.6 |
0.8 |
6.4 |
14.4 |
57 |
|
|
3 x 0.75 |
0.6 |
0.8 |
6.8 |
21.6 |
68 |
|
|
4 x 0.75 |
0.6 |
0.8 |
7.4 |
29 |
84 |
|
|
5 x 0.75 |
0.6 |
0.9 |
8.5 |
36 |
106 |
|
|
2 x 1.00 |
0.6 |
0.8 |
6.8 |
19 |
65 |
|
|
3 x 1.00 |
0.6 |
0.8 |
7.2 |
29 |
79 |
|
|
4 x 1.00 |
0.6 |
0.9 |
8.0 |
38 |
101 |
|
|
5 x 1.00 |
0.6 |
0.9 |
8.8 |
48 |
123 |
|
|
2 x 1.50 |
0.7 |
0.8 |
7.6 |
29 |
87 |
|
|
3 x 1.50 |
0.7 |
0.9 |
8.2 |
43 |
111 |
|
|
4 x 1.50 |
0.7 |
1.0 |
9.2 |
58 |
142 |
|
|
5 x 1.50 |
0.7 |
1.1 |
10.5 |
72 |
176 |
|
|
2 x 2.50 |
0.8 |
1.0 |
9.2 |
48 |
134 |
|
|
3 x 2.50 |
0.8 |
1.1 |
10.1 |
72 |
169 |
|
|
4 x 2.50 |
0.8 |
1.1 |
11.2 |
96 |
211 |
|
|
5 x 2.50 |
0.8 |
1.2 |
12.4 |
120 |
262 |
|
|
3 x 4.00 |
0.8 |
1.2 |
11.3 |
115 |
233 |
|
|
4 x 4.00 |
0.8 |
1.2 |
12.5 |
154 |
292 |
|
|
5 x 4.00 |
0.8 |
1.4 |
13.7 |
192 |
369 |
|
|
3 x 6.00 |
0.8 |
1.1 |
13.1 |
181 |
328 |
|
|
4 x 6.00 |
0.8 |
1.3 |
13.9 |
230 |
490 |
|
Appliance-Grade Flexible Wiring For Daily Use
H05VV‑F is developed for electricians, office installers, and facility maintenance professionals who require dependable wiring for devices such as washing machines, refrigerators, vacuum cleaners, and drying machines in indoor environments. Its versatility extends to damp or lightly wet spaces like kitchens and bathrooms, where cords may encounter occasional flexing or movement. This cable is also adaptable within furniture channels or prefabricated wall systems, offering ease of integration in confined assemblies. Recognized among wire and cable experts for its robust yet lightweight design, H05VV‑F defines practical utility for everyday electrical connectivity tasks, rooted in European harmonized standards.
Composed With Standardized Multi-Stranded Copper And PVC Sheath
Constructed with flexible Class 5 copper wire conductors in compliance with EN 60228 and VDE 0295, H05VV‑F employs PVC insulation (TI2) and sheath (TM2) as per EN 50363 specifications. It maintains a working voltage of 300/500 V, a test voltage of 2000 V, and demonstrates breakdown resistance up to approximately 4000 V. Bending radius limits are 7.5× cable diameter in dynamic applications and 4× in fixed installations. Its temperature tolerance ranges from –5 °C to +70 °C under movement and drops to –40 °C to +70 °C when static. Flame retardance aligns with IEC 60332‑1 standards, reinforcing safety. These feature details make H05VV‑F a dependable component in cable manufacturing for safe, standardized indoor applications.
Common Use In Household, Office, And Modular Installations
H05VV‑F is the preferred cable for powering portable or semi-fixed appliances in residential and office settings. It functions effectively in organized environments such as modular furniture wiring, built-in kitchen units, flexible office setups, or temporary equipment connections. Its oil-resistant PVC finishes and trusted mechanical reliability cater to manufacturers and suppliers requiring dependable indoor connectors. Frequently chosen by industrial cable suppliers for its compliance with both safety regulations and dynamic handling demands, H05VV‑F achieves wide adoption across consumer wiring scenarios.
Product Advantages
High Flexibility Enables Neat Routing And Reconfiguration
The Class 5 stranded copper core allows installers to bend and fit the cable within tight routes, behind cabinets, or through cable trunking without compromising conductor integrity. For cable manufacturing specialists, this flexibility allows modular design and efficient reconfiguration—especially relevant in evolving workspaces and multi-use interiors where wiring layout must adapt during renovation or upgrade.
Safety-Assured PVC Build Reduces Fire Risk
The PVC insulation and outer jacket are engineered to resist abrasion, moderate heat, and mechanical impact while complying with flame-retardant regulations. By limiting fire propagation and meeting IEC 60332‑1, H05VV‑F offers elevated safety in domestic or commercial appliances, reinforcing trust for quality-conscious wire and cable professionals who prioritize risk mitigation without sacrificing ease of installation.
Compliance With Harmonized European Approvals
H05VV‑F meets high standardization benchmarks including EN 50525‑2‑11, VDE 0285-525-2-11, HAR certification, and is RoHS-compliant. This broad approval framework ensures suitability in diverse supply chains and export markets, a key advantage for wire manufacturers and installers seeking consistent quality and legal alignment across multiple regions.
Use Scenarios
Residential Electricians Installing Household Appliances
Electricians in domestic settings rely on H05VV‑F for safe, flexible connections to appliances in tight or concealed spaces. Its ability to withstand moderate bending and its durable PVC sheath make it ideal for routing behind walls or cabinetry, especially for fixtures subject to frequent use or movement.
Office Fit-Out Specialists Wiring Modular Workstations
In modular office environments, desk layouts and configurations often shift. H05VV‑F's lightweight flexibility and quick handling enable efficient wiring of desk-mounted devices, charging points, and movable fixtures, meeting the agility demands of modern workspace solutions offered by industrial cable suppliers.
Furniture Manufacturers Integrating Power Into Built-In Units
Producers of modular furniture or prefabricated cabinetry require cables that conform to compact assemblies yet deliver reliable current. H05VV‑F fits these needs, allowing hidden wiring paths and safe appliance connectivity inside built-in cabinets, contributing to a clean aesthetic while maintaining compliance with safety standards essential to cable manufacturing excellence.
About Us
JINDA CABLE specializes in supplying quality wire and cable solutions, blending technical precision with broad application flexibility. With expertise in flexible appliance cords like H05VV‑F, industrial power cables, photovoltaic conductors, and OEM-custom wiring, the company serves residential, commercial, and light industrial needs. Known for rigorous certification, consistent quality, and delivery reliability, JINDA enjoys partnerships with wire manufacturers, integrators, and industrial cable suppliers globally, establishing its products as trusted infrastructure elements across over 50 markets.
Request A Quote For H05VV‑F Power Cable Solutions Today!
FAQ
What voltage range does H05VV‑F support?
It operates at 300/500 V with test capability up to 2000 V, suitable for AC household and office appliances.
What temperature conditions can it withstand?
Dynamic use: –5 °C to +70 °C; fixed installation: –40 °C to +70 °C, making it versatile for diverse indoor environments.
Is H05VV‑F flame-retardant?
Yes, it meets IEC 60332‑1 for fire safety, reducing ignition spread during electrical faults.
How flexible is the cable?
It supports a minimum bending radius of 7.5× its diameter in flexible use and 4× in fixed installation, suitable for compact routing.
Can it be used outdoors?
No, it is intended for indoor use only—specifically areas with moderate mechanical stress, not exposed outdoor or heavy industrial environments.
