Application and description：
This low smoke halogen-free cable is very flexible and is mainly used for mobile services and is suitable for
environments where low smoke and halogen-free are required under fire conditions. This cable can withstand
medium mechanical stress and is used in industrial and agricultural plant machines, motors and some transport
machines, wind power stations and agricultural
Standards and certification：
HD22.13S1&A1, VDE-0282 Part-13, CEI 20-19 p.13, IEC 60245-4, IEC 60754, EN 61034, CE Low Voltage
73/23/EEC & 93/68/EEC Directive. ROHS certification
Cable structure：
- Multiple strands of soft bare copper conductor
- Comply with VDE-0295 Cl 5, IEC 60228 CL-5
- Halogen-free rubber EI8 insulation, according to EN 50363-5
- Color coding follows VDE-0293-308
- Black halogen-free rubber EM8 sheath
Technical characteristics：
- Operating voltage: 450/750 V
- Fixed voltage: 600/1000 V
- Test voltage: 2500 V
- Dynamic bending radius :6 x Ø
- Fixed installation bending radius: 4.0 x Ø
- Operating temperature during application: -5º C to +70º C
Flame retardant: IEC 60332.3C1, NF C 32-070
- Insulation resistance: 20 MΩ x km
Cable parameter：
|
Number of cores x conductor cross-sectional area
# x mm²
|
Nominal insulation thickness mm
|
Nominal sheath thickness mm
|
Nominal outer diameter mm
|
Nominal copper
Weight kg/Km
|
Nominal cable
Weight kg/Km
|
|
2 x 1
|
0.8
|
1.3
|
7.7-10
|
19
|
96
|
|
3 x 1
|
0.8
|
1.4
|
8.3-10.7
|
29
|
116
|
|
4 x 1
|
0.8
|
1.5
|
9.2-11.9
|
38
|
143
|
|
5 x 1
|
0.8
|
1.6
|
10.2-13.1
|
46
|
171
|
|
1 x 1.5
|
0.8
|
1.4
|
5.7-7.1
|
14.4
|
58.5
|
|
2 x 1.5
|
0.8
|
1.5
|
8.5-11.0
|
29
|
120
|
|
3 x 1.5
|
0.8
|
1.6
|
9.2-11.9
|
43
|
146
|
|
4 x 1.5
|
0.8
|
1.7
|
10.2-13.1
|
58
|
177
|
|
5 x 1.5
|
0.8
|
1.8
|
11.2-14.4
|
72
|
216
|
|
7 x 1.5
|
0.8
|
2.5
|
14.5-17.5
|
101
|
305
|
|
12 x 1.5
|
0.8
|
2.9
|
17.6-22.4
|
173
|
500
|
|
14 x 1.5
|
0.8
|
3.1
|
18.8-21.3
|
196
|
573
|
|
18 x 1.5
|
0.8
|
3.2
|
20.7-26.3
|
274
|
755
|
|
24 x 1.5
|
0.8
|
3.5
|
24.3-30.7
|
346
|
941
|
|
36 x 1.5
|
0.8
|
3.8
|
27.8-35.2
|
507
|
1305
|
|
1 x 2.5
|
0.9
|
1.4
|
6.3-7.9
|
24
|
72
|
|
2 x 2.5
|
0.9
|
1.7
|
10.2-13.1
|
48
|
173
|
|
3 x 2.5
|
0.9
|
1.8
|
10.9-14.0
|
72
|
213
|
|
4 x 2.5
|
0.9
|
1.9
|
12.1-15.5
|
96
|
237
|
|
5 x 2.5
|
0.9
|
2.0
|
13.3-17.0
|
120
|
318
|
|
7 x 2.5
|
0.9
|
2.7
|
16.5-20.0
|
168
|
450
|
|
12 x 2.5
|
0.9
|
3.1
|
20.6-26.2
|
288
|
729
|
|
14 x 2.5
|
0.9
|
3.2
|
22.2-25.0
|
337
|
866
|
|
18 x 2.5
|
0.9
|
3.5
|
24.4-30.9
|
456
|
1086
|
|
24 x 2.5
|
0.9
|
3.9
|
28.8-36.4
|
576
|
1332
|
|
36 x 2.5
|
0.9
|
4.3
|
33.2-41.8
|
1335
|
1961
|
|
1 x 4
|
1
|
1.5
|
7.2-9.0
|
38
|
101
|
|
3 x 4
|
1
|
1.9
|
12.7-16.2
|
115
|
293
|
|
4 x 4
|
1
|
2.0
|
14.0-17.9
|
154
|
368
|
|
5 x 4
|
1
|
2.2
|
15.6-19.9
|
192
|
450
|
|
12 x 4
|
1
|
3.5
|
24.2-30.9
|
464
|
1049
|
Product AdvantagesFlame‑Safe Insulation For Human‑Centric SpacesH07ZZ‑F uses LSZH materials that limit smoke density and corrosive gas release under fire conditions—critical in buildings with high occupancy. The flame-retardant rubber conforms to stringent IEC fire ratings, ensuring safety without external suppression systems. This aligns well with requirements of cable manufacturing projects focused on minimizing fire hazards.Highly Flexible Copper Core Reduces Mechanical StrainThe Class 5 stranded conductor enhances flexibility, making routing through tight spaces straightforward. Static bending down to 4× cable diameter and dynamic bending even more forgiving—this flexibility prevents conductor fatigue and supports efficient handling during installation in demanding setups, valued by industrial cable suppliers who manage complex cable layouts.UV & Ozone Resistance For Indoor‑Outdoor AdaptabilityThough primarily suited for interior use, H07ZZ‑F's rubber composition resists ozone and mild UV exposure, allowing short-term outdoor deployment in protected conditions. This resistance makes it appropriate for mobile equipment that frequently moves between environments without sacrificing safety, appealing to power cable applications requiring cross-environment resilience. Use ScenariosStage Tech Teams Powering Mobile Lighting RigsStage lighting crews often transport and reconfigure power setups under time pressure. H07ZZ‑F delivers necessary voltage capacity with flexibility for rapid uncoiling and positioning, while its low‑smoke properties ensure safety during rehearse or live events. This cable suits professionals needing both handling ease and compliance in wire manufacturers’ supply chains.Facilities Engineers Wiring Backup Power SystemsIn facilities housing critical systems, such as hospitals or server rooms, UPS and backup systems must be wired with cables that ensure safety under fault conditions. The H07ZZ‑F’s fire-safe rubber construction, voltage rating, and flexibility make it an ideal choice for technicians installing and maintaining electrical resilience infrastructure, reinforcing trust in cable manufacturing standards.Rental Service Operations Supplying Mobile Industrial ToolsCompanies offering mobile power tools or equipment for construction sites favor LSZH-rated cables to meet safety requirements and reduce hazard potential. H07ZZ‑F withstands moderate mechanical stress and environmental exposure while maintaining safety properties—perfect for operators providing safe, reliable equipment setups as part of wire and cable rental offerings.
About UsJINDA CABLE is a respected developer and manufacturer of advanced wire and cable solutions, serving global markets with premium performance products. With expertise in power and control cabling, including specialist LSZH power cables like H07ZZ‑F, JINDA meets rigorous safety and reliability standards. Their product suite covers low‑voltage, photovoltaics, flame‑retardant, and flexible rubber cables. With global reach and deep technical proficiency, the company supports specification, installation, and customization needs across sectors—from critical infrastructure to public venue safety—earning credibility among wire manufacturers, contractors, and EPC partners.Request A Quote For H07ZZ‑F Low‑Smoke Cable Solutions Now! FAQ
What is H07ZZ‑F’s voltage rating?It is rated for 450/750 V and tested up to 2500 V, suitable for control and power circuits under safety regulations.Is it safe for public or dense spaces?Yes. Its LSZH construction minimizes smoke and toxic emissions during fire, ensuring safer evacuation and equipment integrity.How flexible is the cable?The cable features Class 5 stranded copper and supports a minimum bending radius of 4× diameter (static), making it highly adaptable in tight routing.Can it be used outdoors?It’s designed for indoor use primarily, but its ozone and UV resistance permit limited outdoor use in enclosed or transit scenarios.Does it resist mechanical wear?Yes, it withstands moderate mechanical stress and repetitive handling, suitable for mobile equipment and temporary setups.
